1 to 1 M.2 NVMe SATA Duplicator with
Image backup management
Carry Series -PP281M
No PC/software required to operate the duplicator.
Quick Copy (System & files), All partitions, Whole HDD and Percentage.
Supports all brands of 2.5”/3.5” SATA HDDs and SSDs, and 2.5″/3.5” IDE, iVDR, eSATA, mSATA, Micro SATA, M.2 (NGFF), and CFast with adapters, in both GPT and MBR formats.
Quick erase, Full erase, DoD erase, DoD erase comp, 7-pass erase, Secure erase, Enhanced Secure erase.
Quick copy supports Linux (ext2/ext3/ext4), Mac, NTFS, and FAT16/32.
Store multiple image files from different sources into one master hard disk.
U.2 SSD vs. U.3 SSD: Which Next-Gen Storage Solution is Right for You?
Top 6 Recommended Hard Disk Cloner for Efficient Data Backup and Cloning
Hard Drive Docking Station vs Cloner – Which One is Right for You?
5 Essential Steps for Successful HDD Cloning to Smaller Drives
Data Wipe Software Comparison: Key Features, Pricing, and Challenges
Top 6 SSD in Malaysia for 2024: Speed, Performance & Value Comparison
Key Features
- Four copy modes including Quick (Systems & Files,) Whole Media, All Partitions, Percentage % Copy
- 7 erase modes including Quick erase, Full erase, DoD erase, DoD erase comp, 7-pass erase, Secure erase, Enhanced Secure erase
- Transfer speed up to 9GB/min
- Cross-interface data copy between NVMe and SATA device*.
- Supports M key and B+M key for all M.2 PCIe, M.2 SATA devices, SATA HDD/SSD devices and IDE devices (required adapters).
*Copy OS drive with limited conditions
Overview
U-Reach SP101 is a professional NVMe M.2 SSD and SATA duplicator. Native support NVMe and SATA protocols enables cross-signal and cross-interface duplication for your data. Standalone design no need to connect with the computer.
Four modes of drive duplication including Data Only (Quick COPY), Whole Media, All Partitions, Percentage Copy. Transfer speed is up to 9GB per minute. SP101 is not only a duplicator, but also an eraser. It is capable of erasing 2 drives simultaneously with multiple erase modes including Quick erase, NIST Full erase, DoD erase, DoD erase comp, 7-pass erase, Secure erase, Enhanced Secure erase. It helps your data backup and data wiping process.
Applicable for all M.2 PCIe, M.2 SATA devices, SATA HDD/SSD devices and IDE devices (required adapters). It also support hot swapping.
Specific modular-designed M.2 ports effectively reduce downtime and is cost-effective for long-term ownership.
For added compatibility with different drive types in duplication and quick erase applications, the SP151 supports the use of various drive adapters. The below list of JetMedia adapters have been specifically tested, to ensure compatibility with this NVME/SATA cloner:
2.5inch IDE drives – 25H-IDE
3.5inch IDE drives – 35H-IDE
mSATA drives – MS-SD100
The durable and portable design will be your best tool for your data management.
Application
- It helps IT professionals and system administrators to manage drives effectively.
- Standalone and portable design requires no PC or additional software for data duplication or erase.
- Data backup tool for repair workshop, office professionals, medical staff, government personnel.
- Cross-interface data copy between NVMe and SATA device. ( copy OS with limited conditions)
- 1-to-1 copy or erase up to 2 NVMe/SATA devices simultaneously without a host computer.
| Model | SP101 | |
| Target | 1 to 1 | |
| Specifications | Max speed (GB/ min) | 9GB/min.*Actual performance is dependent on HDD transfer speeds* |
| Capacity | Supports the latest market available capacity Designed support capability up-to 18TB+ | |
| Operating Type | Stand-alone, FPGA-based operation (Non PC-based) | |
| Supported Languages | English, Japanese | |
| LCD Display | Backlit Monochrome LCD Display | |
| LEDs | 3 LED Indicators per Port: Yellow (Power), Green (Pass), and Red (Fail) | |
| Control Panel | 4 Push Buttons(▲, ▼, OK, ESC) | |
| Features | Copy | Quick Copy (Systems & Files Copy), All Partition Copy, Whole Device Copy, Percentage Copy |
| Compare | Bit by Bit data comparison | |
| Erase | Quick Erase, Full Erase (NIST 800-88), and DoD Erase | |
| Compatibilities | Compatible Devices | NGFF (M.2): 2230, 2242, 2260, 2280, PCI-e SSD (full and low profiles) |
| Compatible Devices (with required adapter) | SATA HDD/SSD, U.2(SFF8639) | |
| 2.5″, 3.5” IDE HDD, mSATA SSD, micro SATA, eSATA, iVDR, M.2(NGFF), Cfast, SATA DOM. | ||
| Supported O/S | All (Windows, Mac, Linux, and other stand-alone systems) | |
| Supported Formats | Quick Copy: FAT16/32/64, Windows (NTFS), Linux (Ext2/Ext3/Ext4), and Mac (HFS, HFS+,HFSX) Whole Device Copy: All Formats, including proprietary formats | |
| Hardware Specifications | Temperature range | Working temperature: 5°C ~ 45°C |
| Storage temperature: -20°C ~85°C | ||
| Humidity range | Working humidity: 20% ~ 95% | |
| Storage humidity: 5% ~ 95% | ||
| Dimension | 11.5 in. x 9 in. x 3 in. | |
| Weight | 3.6 lbs. | |
| Power | 60W (12V 5A) | |
| Power Supply | Universal Power: 115VAC or 230VAC, 50/60Hz | |
| Certification | FCC, CE, RoHS | |
FAQ for PP281M 1-to-1 M.2 NVMe SATA Duplicator with Hard Drive Image Backup
What types of storage devices does the PP281M support?
It supports M.2 NVMe and SATA SSDs, offering versatile compatibility for data duplication and image backup.Does the PP281M require a computer to operate?
No, this duplicator is a standalone device, meaning it does not require a PC or additional software to function.What is the maximum duplication speed?
The PP281M can duplicate at speeds up to 24GB per minute, ensuring fast and efficient data transfer.Can I use the PP281M for hard drive image backup?
Yes, this device allows you to store and manage multiple disk images for efficient backup and restoration. Can also download or upload the GOB image file from PC or PP281M.What secure erase methods are available?
The duplicator includes Quick Erase, Full Erase, DoD Erase, and Secure Erase, meeting industry data sanitization standards.Can I clone drives with different capacities?
Yes, but the target drive must have equal or greater capacity than the source drive to ensure a successful duplication.Does the duplicator verify copied data?
Yes, it features a bit-by-bit comparison function to ensure data accuracy and integrity.What devices can be supported with an adapter?
With an optional adapter, the PP281M can support additional storage formats, including mSATA and CFast drives.Will the duplicator modify the source drive?
No, the source port is equipped with a write-blocker, ensuring that the original data remains unchanged.
